ACL 2015+ Dodge 6.2L V8 Standard Size Race Series Main Bearing Set 5M2221H-STD

Crankshaft Main Bearing Set 5 - Standard Size

ACL RACE Series performance engine bearings are recognized as a premier brand throughout the motorsports world. RACE Series rod and main bearings are standard components in Race engines that have set records and won championships from Mexico to Bonneville - from sport compact drift racing to small block NASCAR, IHRA and NHRA cmpetitions. The unique combination of design, metallurgy and engineering provides RACE Series performance bearings with the endurance and capability to perform where others cannot. These exceptional bearings are available for a variety of American, Asian and European performance engines

ADDITIONAL INFORMATION

ACL 2015+ Dodge 6.2L V8 Standard Size Race Series Main Bearing Set

Grade Type: Performance
Max Wall: 2.442 MM
Max Wall: 0.0961 IN
Outside Diameter: 2.7516 IN
Outside Diameter: 69.893 MM
Outside Diameter: 69.906 MM
Outside Diameter: 2.752 IN
Shaft Diameter: 2.559 IN
Shaft Diameter: 64.996 MM
Shaft Diameter: 65.004 MM
Shaft Diameter: 2.560 IN
Width: 21.10 MM
Width: 0.831 IN

Interchange: Clevite MS-2296H

FITMENT NOTES

2021-2024 Ram 1500 (Engine Designation: ESD); 2015-2018 Dodge Challenger (Aspiration: Supercharged & Engine Designation: ESD & Cylinder Head: OHV & Liter: 6.2 & Engine(cc): 6166 & Engine(ci): 376 & Cylinder: 8 & Block: V & Bore(in): 4.09 & Bore(mm): 103.9 & Stroke(in): 3.58 & Stroke(mm): 90.9 & HP: 707 & Engine VIN: 9 & Valves: 16 & Ignition: Distributorless & Fuel: GAS & Engine Version: HEMI); 2015-2020 Dodge Charger (Aspiration: Supercharged & Engine Designation: ESD & Cylinder Head: OHV & Liter: 6.2 & Engine(cc): 6166 & Engine(ci): 376 & Cylinder: 8 & Block: V & Bore(in): 4.09 & Bore(mm): 103.9 & Stroke(in): 3.58 & Stroke(mm): 90.9 & HP: 707 & Engine VIN: 9 & Valves: 16 & Ignition: Distributorless & Fuel: GAS & Engine Version: HEMI); 2018-2021 Jeep Grand Cherokee (Aspiration: Supercharged & Engine Designation: ESD & Cylinder Head: OHV & Liter: 6.2 & Engine(cc): 6166 & Engine(ci): 376 & Cylinder: 8 & Block: V & Bore(in): 4.09 & Bore(mm): 103.9 & Stroke(in): 3.58 & Stroke(mm): 90.9 & HP: 707 & Engine VIN: 9 & Valves: 16 & Ignition: Distributorless & Fuel: GAS & Engine Version: HEMI)
