DBA 2010+ Camaro V8 SS Front Drilled & Slotted 5000 Series 2 Piece Rotor Assembled w/ Black Hat

Front 5000 Series XS Brake Rotor

XS provides all the benefits of 5000 Series with a premium non-directional cross drilled and slotted design resulting in better braking performance plus a variety of finishes available on the rotor hub.

Sharing all the benefits of the 4000 SERIES 5000 SERIES rotors are a composite 2 piece direct replacement brake rotor. We use only the highest quality materials to ensure optimal performance under the most strenuous circumstances combining high carbon cast iron rings with aerospace grade aluminium hats (T6061-T6) held together with National Aerospace Standards (NAS) bolts and crimp nuts.

Slots/chamfers for quiet & responsive feel;
DBA offers direct replacement brake rotors designed for drivers seeking upgraded performance braking above and beyond standard OE levels. Its performance series are cast from high carbon alloyed iron and undergo Thermal Stability Profiling (TSP) allowing DBA?s metallurgy to handle increased stress and heat generated under intense braking applications time and time again. Featuring DBA?s Kangaroo Paw ventilation that implements a series of 144 diamond and teardrop patterned pillars DBA achieves up to a 30% increase in surface area and 20% improvement in cooling efficiency (as compared to a traditional straight vane design).

ADDITIONAL INFORMATION

DBA 2010+ Camaro V8 SS Front Drilled & Slotted 5000 Series 2 Piece Rotor Assembled w/ Black Hat

Title: DBA Front 5000 Series XS Brake Rotor - DBA52604BLKXS
Discard Thickness: 32 MM
Nominal Thickness: 32 MM
Overall Height: 50 MM
Outside Diameter: 355 MM
Surface Type: Drilled Slotted
Solid Or Vented Type Rotor: Vented
Center Hole Diameter: 67.4 MM
Stud/Lug Hole Quantity: 5

FITMENT NOTES

2009-2009 Pontiac G8
2010-2015 Chevrolet Camaro
2014-2017 Chevrolet SS
