Mishimoto 11-16 Ford 6.7L Powerstroke Air-To-Water Intercooler - Micro-Wrinkle Blue

Ford 6.7L Powerstroke Air-to-Water Performance Intercooler 2011-2016 Blue

The 2011-2016 Ford Super Duty equipped with the 6.7L Powerstroke is one of the most capable and reliable trucks on the road today. But when Mishimoto heard about 6.7L Powerstroke air-to-water intercoolers leaking internally we set to work making the 6.7L Powerstroke even better. The Mishimoto 6.7L Powerstroke intercooler brings even more reliability to the 6.7L by ditching the stamped and stacked plate stock design. Instead our intercooler is built with cast aluminum end tanks that are precision TIG welded to the robust bar-and-plate core. The cast end-tanks reduce potential failure points making them more reliable than cut and welded tanks. Aside from being more durable than stock the Mishimoto 6.7L Powerstroke intercooler also flows better. Flow bench testing showed that the Mishimoto intercooler flowed 22-percent better than the stock cooler. On the dyno that extra flow provided our stock 6.7L with 40 lb. ft. more torque. This cooler is available with a powder coated sleek silver stealthy micro-wrinkle black or micro-wrinkle blue finish to match any style. Like all Mishimoto products our 2011-2016 Ford 6.7L Powerstroke Air-to-Water intercooler is covered by our Mishimoto Lifetime Warranty.

Direct fit for all 2011+ Ford 6.7L Powerstroke
Patent #D907 063
Mishimoto Lifetime Warranty
22% Greater air flow than stock 6.7L Powerstroke intercooler
Dyno-proven 40 lb-ft torque gains without other modifications
Cast end tanks are more durable than brazed or welded end tanks eliminating potential leak points
Bar-and-plate core for efficient cooling and unsurpassed strength
No tune required - Intercooler can be installed on a completely stock or modified truck
Includes Mishimoto mandrel-bent aluminum intercooler pipes for greater durability
Includes Mishimoto Silicone Boots with DuraCore technology and Constant Tension Worm Gear Clamps
Available in a Micro-Wrinkle Silver Micro-Wrinkle Black or Micro-Wrinkle Blue powder coated finish

ADDITIONAL INFORMATION

CARB EO Number: D-759-4
Install Difficulty: 3
OptionLabel: Micro-Wrinkle Blue
SellingPoint01: Direct fit for all 2011-2016 Ford 6.7L Powerstrokes
SellingPoint02: 22-percent Greater air flow than stock 6.7L Powerstroke intercooler
SellingPoint03: Dyno-proven 40 lb-ft torque gains without other modifications
SellingPoint04: Cast end tanks are more durable than brazed or welded end tanks, eliminating potential leak points
SellingPoint05: Bar-and-plate core for efficient cooling and unsurpassed strength
SellingPoint06: No tune required-Intercooler can be installed on a completely stock or modified truck
SellingPoint07: Available in a Micro-Wrinkle Silver, Micro-Wrinkle Black, or Micro-Wrinkle Blue powder coated finish
SellingPoint08: Patent numberD907,063
SellingPoint09: Mishimoto Lifetime Warranty
SellingPoint10: N/A
SellingPoint11: N/A
SellingPoint12: N/A
SellingPoint13: N/A
SellingPoint14: N/A
SellingPoint15: N/A
TechSpec Applications: 2011-2016 Ford Super Duty 6.7L Powerstroke
TechSpec Centerline Radius: N/A
TechSpec Chassis Codes: N/A
TechSpec Core Height (in): 6.69
TechSpec Core Length (in): 10.59
TechSpec Core Thickness (in): 4.48
TechSpec Core Type: Bar-and-Plate
TechSpec Engine Codes: N/A
TechSpec Includes: (1) Mishimoto Air-to-Water Intercooler--Mounting Hardware--Mishimoto Lifetime Warranty
TechSpec Inlet (in): N/A
TechSpec Installation Notes: N/A
TechSpec Maximum Recommended Boost Pressure (PSI): N/A
TechSpec Maximum Recommended Horsepower: N/A
TechSpec Note: This intercooler will not fit with 2017+ models with the Mishimoto 2017+ 6.7L Powerstroke Intercooler Piping installed. If you have already purchased our 2017+ intercooler piping and would like to add this intercooler,----Patent #D907063
TechSpec Outlet (in): N/A
TechSpec Overall Height (in): N/A
TechSpec Overall Length (in): N/A
TechSpec Overall Width (in): N/A
TechSpec Pipe Diameter: N/A
TechSpec Pipe Length: N/A
TechSpec Pipe Shape: N/A
TechSpec Weight (lbs): N/A

FITMENT NOTES

2011-2016 Ford F-250 Super Duty
2011-2016 Ford F-350 Super Duty
2011-2016 Ford F-450 Super Duty
2011-2016 Ford F-550 Super Duty
