BMR 67-69 1st Gen F-Body Front Hollow 1.25in Sway Bar Kit w/ Bushings - Red

SB004R
Availability: Item usually ships within 24 hours
Was: $334.18
Sale: $319.95
Save: 4%
Save: $14.23
Qty:
Free Shipping!

Description

BMR Suspension designed the SB004 sway bar kit for street performance, autocross, and road race applications.

The two primary functions of sway bars are to control body roll and to determine the understeer or oversteer behavior of a vehicle. Stock sway bars have low torsional spring rates because they are manufactured from small diameter bar stock or tubing. BMR Suspension?s SB004 front sway bar was designed by factoring in the vehicle weight, application, motion ratio, coil spring rate, and adjustability requirements. Manufactured from heavy-wall 1.25-inch DOM tubing, the SB004 is cold formed to better resist torsional fatigue and retain its "memory" far longer than the hot-formed bars used by many competitors. The sway bar is CNC-formed for exact manufacturing tolerances and repeatable high quality. The SB004 attaches to your Nova with 88-durometer polyurethane bushings, reducing the deflection from the stock rubber bushings. These bushings are molded from 88-durometer, low-deflection, polyurethane, and are internally fluted to keeps grease in the bushing. The fabricated laser cut, TIG-welded steel sway bar end links are reinforced to minimize deflection.

Fits First-Gen GM F-body and GM X-body
Designed for street performance, autocross, and road race applications
Dramatically reduces body roll
200% increase is sway bar rate over stock sway bar
Cold formed to better resist torsional fatigue
Manufactured from 1.25-inch heavy-wall DOM tubing for increased strength
88-durometer, greasable polyurethane bushing
Zinc-plated inner sleeves
Durable powdercoat finish
1-2-hour installation time
Proudly designed in the U.S.A.
Proudly made in the U.S.A.

ADDITIONAL INFORMATION

BMR 67-69 1st Gen F-Body Front Hollow 1.25in Sway Bar Kit w/ Bushings - Red

Front Sway Bar Adjustable: Fixed
Front Sway Bar Diameter (in): 1.25 inches
Front Sway Bar Diameter (mm): 32.0 mm
Front Sway Bar Type: Hollow
Mounting Hardware Included: Yes
Position: Front
Quantity: Sold as a kit
Sway Bar Finish: Red powdercoated
Sway Bar Material: Steel
Title: BMR Suspension SB004R Sway Bar Kit With Bushings, Front, Hollow 1.25"

FITMENT NOTES

1967-1969 Chevrolet Camaro
1967-1969 Pontiac Firebird
1969-1974 Chevrolet Nova

Compatible Vehicles

Details

Categories

Shipping Information

  • Item Requires Shipping
  • 17.0 lbs.
  • W10.0000” x H59.0000” x L5.0000”
  • Free Shipping!
