BMR 10-11 5th Gen Camaro Front & Rear Sway Bar Kit w/ Bushings - Red

BMR Suspension designed the SB030 sway bar kit for street performance, autocross, and road race applications.

The two primary functions of sway bars are to control body roll and to determine the understeer or oversteer behavior of a vehicle. Stock sway bars have low torsional spring rates because they are manufactured from small diameter bar stock or tubing. BMR Suspension?s SB030 front and rear sway bar kit was designed by factoring in the vehicle weight, application, motion ratio, coil spring rate, and adjustability requirements. Manufactured from heavy-wall 29mm DOM tubing, the SB030 is cold formed to better resist torsional fatigue and retain its "memory" far longer than the hot-formed bars used by many competitors. The sway bar is CNC-formed for exact manufacturing tolerances and repeatable high quality. Thrust washers are welded to the bar to locate the sway bar bushing mounts. This is critical as it properly locates the sway bar and prevents lateral movement during hard cornering maneuvers. The sway bar mounts to the car using polyurethane bushings. These bushings are molded from 88-durometer, low-deflection, polyurethane, and are internally fluted to keeps grease in the bushing. The steel sway bar mounting brackets are reinforced to minimize deflection. The sway bar is 3-way adjustable to tune the amount of torsional spring rate and to determine the handling characteristics (understeer/oversteer) of the vehicle.

Fits all 2010-2012 Chevrolet Camaros
Designed for street performance, autocross, and road race applications
Dramatically reduces body roll
98%-214% increase (front), 99%-301% increase (rear) in sway bar rate
Cold formed to better resist torsional fatigue
Manufactured from 29mm (front), and 25mm (rear) heavy-wall DOM tubing for increased strength
Three-way adjustable for street and track use
Adjustability allows for fine-tuning of suspension
88-durometer, greasable polyurethane bushing
Zinc-plated inner sleeves
Durable powdercoat finish
3-4 hour installation time
Proudly designed in the U.S.A.
Proudly made in the U.S.A.

ADDITIONAL INFORMATION

BMR 10-11 5th Gen Camaro Front & Rear Sway Bar Kit w/ Bushings - Red

Front Sway Bar Adjustable: 3-position
Front Sway Bar Diameter (in): 1.125 inches
Front Sway Bar Diameter (mm): 29.0 mm
Front Sway Bar Type: Hollow
Mounting Hardware Included: No
Position: Front and rear
Quantity: Sold as a kit
Rear Sway Bar Adjustable: 3-position
Rear Sway Bar Diameter (in): 1.00 inches
Rear Sway Bar Diameter (mm): 25.0 mm
Rear Sway Bar Type: Hollow
Sway Bar Finish: Red powdercoated
Sway Bar Material: Steel
Title: BMR Suspension SB030R Sway Bar Kit With Bushings, Front (SB016) And Rear (SB017)

FITMENT NOTES

2010-2012 Chevrolet Camaro
