BMR 67-69 1st Gen F-Body Rear Lowering Leaf Springs (2in Drop) - Black

The SP057 leaf springs also come with Teflon antifriction pads for smooth, quiet travel through the spring's range of motion, which further reduces NVH.

Leaf springs do much more than simply supporting the weight of the vehicle. They are responsible for locating the axle, setting pinion angle, and controlling rearend movement. This makes them a critical part of the rear suspension. BMR's leaf springs give a superior option to stock leaf springs that sag, rust, and do little to control axle wrap and wheelhop as they get older. The SP057 feature a 2-inch drop, three leafs, and a 190 lb/in spring rate, which reduces body roll without increasing rear oversteer. This commonly happens with too much spring rate. BMR's spring design, combined with precise clamp locations give you less wheel hop and more axle control. This design reduces axle wrap, which causes the spring to load and unload. By eliminating this oscillation, wheel hop is minimized and traction is improved. Each spring comes with new bushings in the front and rear. Other companies make you buy rear bushings separately, but BMR includes them. The SP057 leaf springs also come with Teflon antifriction pads for smooth, quiet travel through the spring's range of motion, which further reduces NVH. BMR designed the SP057s for street performance, drag race, and handling applications. Lowering springs are not only a great way to add an aggressive look to your 1st-Gen F-body, but they also improve the handling capabilities at the same time. By adding BMR's 2-inch drop leaf springs, you will lower the rear center of gravity and reduce body roll, which improves handling. New bushings greatly reduce the deflection seen in old worn out bushings. New rubber bushings in the front give you a smooth quiet ride, and the polyurethane rear bushings improve handling. To complete the install, you can reuse your original hardware, or purchase new hardware from BMR (RH015), which includes new U-bolts, polyurethane spring pads, stainless steel shackles. Combine with BMR front lowering springs for a level, aggressive stance with huge improvements in handling and performance.

Increased spring rate 190 lb/in
Reduced body roll
Increased handling
Dramatically reduces wheel hop
Comes with new bushings (front and rear)
Stainless steel replacement shackles and front and rear hardware is also available (RH015)
Rubber front bushing
Polyurethane rear bushing
Three leaf design
Accurate arch, load capacity, and durability.
2.5-inch wide
Shot peened
4-inch free arch
Combine with BMR front lowering springs for a level, aggressive stance
Designed for street performance, drag Race, handling applications
Durable black coating

ADDITIONAL INFORMATION

BMR 67-69 1st Gen F-Body Rear Lowering Leaf Springs (2in Drop) - Black

Bushing Color: Black
Bushing Material: Polyurethane
Bushings Included: Yes
Drop, Rear: 2.0 inches
Leaf Spring Width (in): 2.5 inches
Notes: Will not work with Slide A Link Traction Bars
Progressive Rate Spring, Rear: Yes
Quantity: Sold as a pair
Spring Finish: Black painted
Spring Position: Rear
Spring Rate, Rear (lbs/in): 190 lbs/in
Spring Type: Leaf
Title: BMR Suspension SP057 - Lowering Leaf Spring, Rear, 2 Inch Drop - 1967-1981 Camaro & Firebird, 1968-1974 Nova
Title: BMR Suspension SP057 - Lowering Leaf Spring, Rear, 2 Inch Drop - 1967-1981 Camaro & Firebird, 1968-1974 Nova

FITMENT NOTES

1967-1981 Chevrolet Camaro
1967-1981 Pontiac Firebird
1969-1974 Chevrolet Nova
