ACL BMW N54/N55/S55B30 3.0L Inline 6 Race Series High Performance Rod Bearing Set 6B1584HX-STD

Connecting Rod Bearing Set 6 - Standard Size with extra .025mm (0.001") oil clearance (thinner)

ACL RACE Series performance engine bearings are recognized as a premier brand throughout the motorsports world. RACE Series rod and main bearings are standard components in Race engines that have set records and won championships from Mexico to Bonneville - from sport compact drift racing to small block NASCAR, IHRA and NHRA cmpetitions. The unique combination of design, metallurgy and engineering provides RACE Series performance bearings with the endurance and capability to perform where others cannot. These exceptional bearings are available for a variety of American, Asian and European performance engines

ADDITIONAL INFORMATION

ACL BMW N54/N55/S55B30 3.0L Inline 6 Race Series High Performance Rod Bearing Set

Grade Type: Performance
Max Wall: 1.78 MM
Max Wall: 0.0701 IN
Outside Diameter: 53.616 MM
Outside Diameter: 2.1109 IN
Outside Diameter: 53.6 MM
Outside Diameter: 2.1102 IN
Shaft Diameter: 49.993 MM
Shaft Diameter: 1.9682 IN
Shaft Diameter: 49.973 MM
Shaft Diameter: 1.9674 IN
Width: 0.691 IN
Width: 17.55 MM

FITMENT NOTES

2011-2013 BMW 335is; 2011-2012 BMW 740Li; 2011-2013 BMW 325i; 2008-2010 BMW 535i; 2010-2012 BMW 740i; 2011 BMW 1 Series M; 2009-2016 BMW Z4; 2007-2010 BMW 335i; 2008 BMW 535xi; 2007-2008 BMW 335xi; 2008-2010 BMW 135i; 2008-2010 BMW X6; 2009-2010 BMW 535i xDrive; 2009-2010 BMW 335i xDrive
