ACL VW 2.0L TSI/TFSI EA888 4cyl Standard Size High Performance Main Bearing Set w/.001 Oil Clearance 5M5563HX-STD

5M5563HX-STD
Limited Supply: only 5 remaining
Availability: Item usually ships within 24 hours
Was: $143.89
Sale: $126.51
Save: 12%
Save: $17.38
Qty:
Free Shipping!

Description

Main Bearing set 5 - Standard Size with extra .025mm (0.001") oil clearance

ACL RACE Series performance engine bearings are recognized as a premier brand throughout the motorsports world. RACE Series rod and main bearings are standard components in Race engines that have set records and won championships from Mexico to Bonneville - from sport compact drift racing to small block NASCAR, IHRA and NHRA cmpetitions. The unique combination of design, metallurgy and engineering provides RACE Series performance bearings with the endurance and capability to perform where others cannot. These exceptional bearings are available for a variety of American, Asian and European performance engines

ADDITIONAL INFORMATION

ACL VW 2.0L TSI/TFSI EA888 4cyl Standard Size High Performance Main Bearing Set w/.001 Oil Clearance

Grade Type: Performance
Max Wall: 2.491 MM
Max Wall: 0.0981 IN
Outside Diameter: 63.019 MM
Outside Diameter: 2.4811 IN
Outside Diameter: 63 MM
Outside Diameter: 2.4803 IN
Shaft Diameter: 57.978 MM
Shaft Diameter: 2.2826 IN
Shaft Diameter: 57.958 MM
Shaft Diameter: 2.2818 IN
Width: 15.5 MM
Width: 0.61 IN

FITMENT NOTES

2011 Seat Exeo; 2009 Seat Freetrack; 2007-2013 Seat Leon; 2015-2018 Audi Q3; 2004-2013 Audi A3 Quattro; 2013 Audi A4 allroad; 2013-2018 Audi Q3 Quattro; 2004-2016 Audi A3; 2010-2013 Audi A5 Quattro; 2010-2012 Audi Q5; 2008-2012 Audi S3; 2010-2013 Audi A5; 2012-2013 Audi A6; 2013 Audi A6 Quattro; 2009-2013 Audi A4; 2009-2013 Audi A4 Quattro; 2009-2016 Audi TT; 2009-2015 Audi TT Quattro; 2006-2009 Volkswagen Bora; 2009-2010 Volkswagen Passat CC; 2010 Volkswagen GLI; 2017-2018 Volkswagen Tiguan Limited; 2009-2016 Volkswagen Eos; 2009-2017 Volkswagen Tiguan; 2008-2014 Volkswagen GTI; 2009-2017 Volkswagen CC; 2012-2013 Volkswagen Beetle; 2008-2013 Volkswagen Jetta; 2013 Volkswagen Golf; 2008-2010 Volkswagen Passat

Compatible Vehicles

Details

Shipping Information

  • Item Requires Shipping
  • 0.3 lbs.
  • W2.7600” x H1.0200” x L6.3000”
  • Free Shipping!
