ACL Acura/Honda K20A2/K24A Std Size High Perf w/ Extra Oil Clearance Rod Bearing Set - CT-1 Coated 4B1972HXC-STD

Connecting Rod Bearing Set 4 extra .025mm (0.001") oil clearance (thinner)

ACL RACE Series performance engine bearings are recognized as a premier brand throughout the motorsports world. RACE Series rod and main bearings are standard components in Race engines that have set records and won championships from Mexico to Bonneville - from sport compact drift racing to small block NASCAR, IHRA and NHRA cmpetitions. The unique combination of design, metallurgy and engineering provides RACE Series performance bearings with the endurance and capability to perform where others cannot. These exceptional bearings are available for a variety of American, Asian and European performance engines

ADDITIONAL INFORMATION

ACL Acura/Honda K20A2/K24A Std Size High Perf w/ Extra Oil Clearance Rod Bearing Set - CT-1 Coated

Grade Type: Performance
Max Wall: 1.487 MM
Max Wall: 0.0585 IN
Outside Diameter: 2.008 IN
Outside Diameter: 51.004 MM
Outside Diameter: 51.024 MM
Outside Diameter: 2.0088 IN
Shaft Diameter: 47.98 MM
Shaft Diameter: 1.889 IN
Shaft Diameter: 1.8898 IN
Shaft Diameter: 48 MM
Width: 15.4 MM
Width: 0.606 IN

Interchange: OEM 13211-PPA-003
Clevite CB1861HX

FITMENT NOTES

2004-2008 Acura TSX (Aspiration: Naturally Aspirated & Engine Designation: K24A2 & Cylinder Head: DOHC & Liter: 2.4 & Engine(cc): 2354 & Engine(ci): 144 & Cylinder: 4 & Block: L & Bore(in): 3.43 & Bore(mm): 87.0 & Stroke(mm): 99.0 & Fuel: GAS & Engine Version: VTEC); 2007-2012 Acura RDX (Aspiration: Turbocharged & Engine Designation: K23A1 & Cylinder Head: DOHC & Liter: 2.3 & Engine(cc): 2300 & Cylinder: 4 & Block: L & Bore(in): 3.39 & Bore(mm): 86.0 & Stroke(in): 3.89 & Stroke(mm): 99.0 & Valves: 16 & Fuel: GAS & Engine Version: i-VTEC); 2002-2006 Acura RSX (Aspiration: Naturally Aspirated & Engine Designation: K20A2, K20Z1 & Cylinder Head: DOHC & Liter: 2.0 & Engine(cc): 1998 & Engine(ci): 122 & Cylinder: 4 & Block: L & Bore(in): 3.39 & Bore(mm): 86.0 & Stroke(in): 3.39 & Stroke(mm): 86.0 & Fuel: GAS & Engine Version: VTEC); 2003-2007 Honda Accord (Aspiration: Naturally Aspirated & Engine Designation: K24A4, K24A8 & Cylinder Head: DOHC & Liter: 2.4 & Engine(cc): 2354 & Engine(ci): 144 & Cylinder: 4 & Block: L & Bore(in): 3.43 & Bore(mm): 87.0 & Stroke(mm): 99.0 & Fuel: GAS & Engine Version: VTEC); 2002-2009 Honda CR-V (Aspiration: Naturally Aspirated & Engine Designation: K24A1, K24Z1 & Cylinder Head: DOHC & Liter: 2.4 & Engine(cc): 2354 & Engine(ci): 144 & Cylinder: 4 & Block: L & Bore(in): 3.43 & Bore(mm): 87.0 & Stroke(mm): 99.0 & Fuel: GAS & Engine Version: VTEC, i-VTEC); 2003-2011 Honda Element (Aspiration: Naturally Aspirated & Engine Designation: K24A4, K24A8 & Cylinder Head: DOHC & Liter: 2.4 & Engine(cc): 2354 & Engine(ci): 144 & Cylinder: 4 & Block: L & Bore(in): 3.43 & Bore(mm): 87.0 & Stroke(mm): 99.0 & Fuel: GAS & Engine Version: VTEC)
