ACL Chevrolet V8 396/402/427/454 Race Series Standard Size Main Bearing Set with Extra Oil Clearance 5M829HX-STD

5M829HX-STD
Limited Supply: only 7 remaining
Availability: Item usually ships within 24 hours
Was: $102.60
Sale: $90.01
Save: 12%
Save: $12.59
Qty:
Free Shipping!

Description

Main Bearing set 5 extra .001" oil clearance standard

ACL RACE Series performance engine bearings are recognized as a premier brand throughout the motorsports world. RACE Series rod and main bearings are standard components in Race engines that have set records and won championships from Mexico to Bonneville - from sport compact drift racing to small block NASCAR, IHRA and NHRA cmpetitions. The unique combination of design, metallurgy and engineering provides RACE Series performance bearings with the endurance and capability to perform where others cannot. These exceptional bearings are available for a variety of American, Asian and European performance engines

ADDITIONAL INFORMATION

ACL Chevrolet V8 396/402/427/454 Race Series Standard Size Main Bearing Set with Extra Oil Clearance

Grade Type: Performance
Max Wall: 2.359 MM
Max Wall: 0.0929 IN
Outside Diameter: 74.625 MM
Outside Diameter: 2.938 IN
Outside Diameter: 74.6 MM
Outside Diameter: 2.937 IN
Shaft Diameter: 69.83 MM
Shaft Diameter: 2.7492 IN
Shaft Diameter: 69.804 MM
Shaft Diameter: 2.7482 IN
Width: 26.5 MM
Width: 1.043 IN

Interchange: Clevite MS829HX

FITMENT NOTES

1972-1974 Excalibur Phaeton; 1965-1972 Chevrolet Biscayne; 1969-1972 Chevrolet Brookwood; 1968-1974 Chevrolet C10 Pickup; 1968-1974 Chevrolet C20 Pickup; 1968-1974 Chevrolet C30 Pickup; 1968 Chevrolet Chevy II; 1973-1974 Chevrolet G10 Van; 1973-1974 Chevrolet G30 Van; 1968-1974 Chevrolet K10 Pickup; 1968-1974 Chevrolet K20 Pickup; 1968-1974 Chevrolet K30 Pickup; 1969-1972 Chevrolet Kingswood; 1970-1973 Chevrolet P20 Van; 1970-1974 Chevrolet P30 Van; 1969-1972 Chevrolet Townsman; 1969-1970 Chevrolet Estate; 1965-1973 Chevrolet Chevelle; 1973-1974 Chevrolet G20 Van; 1973 Chevrolet P10 Van; 1986-1989 Chevrolet P60; 1993-1996 Chevrolet GP3500; 1965-1974 Chevrolet Bel Air; 1973-1974 Chevrolet Blazer; 1968-1974 Chevrolet C10 Suburban; 1968-1974 Chevrolet C20 Suburban; 1967-1972 Chevrolet Camaro; 1966-1974 Chevrolet Caprice; 1965-1974 Chevrolet Corvette; 1966-1974 Chevrolet El Camino; 1965-1974 Chevrolet Impala; 1968-1974 Chevrolet K10 Suburban; 1968-1974 Chevrolet K20 Suburban; 1973-1974 Chevrolet Laguna; 1965-1974 Chevrolet Malibu; 1970-1974 Chevrolet Monte Carlo; 1969-1972 Chevrolet Nova; 1966-1986 Chevrolet C50; 1966-1985 Chevrolet C60; 1979 Chevrolet C70; 1968-1974 GMC C15/C1500 Pickup; 1968-1974 GMC C15/C1500 Suburban; 1968-1974 GMC C25/C2500 Pickup; 1968-1974 GMC C25/C2500 Suburban; 1968-1974 GMC C35/C3500 Pickup; 1968-1974 GMC K15/K1500 Pickup; 1968-1974 GMC K15/K1500 Suburban; 1968-1974 GMC K25/K2500 Pickup; 1968-1974 GMC K25/K2500 Suburban; 1968-1974 GMC K35/K3500 Pickup; 1970-1971 GMC P25/P2500 Van; 1970-1974 GMC P35/P3500 Van; 1973-1974 GMC G35/G3500 Van; 1987-1989 GMC P6000; 1981 GMC Brigadier; 1973-1974 GMC Jimmy; 1971-1974 GMC Sprint; 1979 GMC C5000; 1979-1985 GMC C6000; 1979 GMC C7000; 1968-1971 Pontiac Acadian; 1966-1970 Pontiac Laurentian; 1965-1969 Pontiac Beaumont; 1965-1970 Pontiac Strato-Chief; 1966-1970 Pontiac Parisienne; 1969-1974 Iso Grifo

Compatible Vehicles

Details

Shipping Information

  • Item Requires Shipping
  • 0.7 lbs.
  • W4.3300” x H1.7700” x L8.1100”
  • Free Shipping!
