ACL 2000+ Toyota 4 1796cc 2ZZGE 0.001 Clearance Conrod Rod Bearing Set 4B1856HX-STD

Connecting Rod Bearing Set 4 - Standard Size with extra .025mm (0.001") oil clearance (thinner)

ACL RACE Series performance engine bearings are recognized as a premier brand throughout the motorsports world. RACE Series rod and main bearings are standard components in Race engines that have set records and won championships from Mexico to Bonneville - from sport compact drift racing to small block NASCAR, IHRA and NHRA cmpetitions. The unique combination of design, metallurgy and engineering provides RACE Series performance bearings with the endurance and capability to perform where others cannot. These exceptional bearings are available for a variety of American, Asian and European performance engines

ADDITIONAL INFORMATION

ACL 2000+ Toyota 4 1796cc 2ZZGE 0.001 Clearance Conrod Rod Bearing Set

Grade Type: Performance
Max Wall: 1.479 MM
Max Wall: 0.0582 IN
Outside Diameter: 48.024 MM
Outside Diameter: 1.8907 IN
Outside Diameter: 48 MM
Outside Diameter: 1.8898 IN
Shaft Diameter: 45 MM
Shaft Diameter: 1.7717 IN
Shaft Diameter: 44.992 MM
Shaft Diameter: 1.7713 IN
Width: 0.63 IN
Width: 16 MM

Interchange: Clevite CB-1920HX

FITMENT NOTES

2003-2006 Pontiac Vibe (Aspiration: Naturally Aspirated & Engine Designation: 2ZZGE & Cylinder Head: DOHC & Liter: 1.8 & Engine(cc): 1795 & Cylinder: 4 & Block: L & Bore(in): 3.23 & Bore(mm): 82.0 & Stroke(in): 3.35 & Stroke(mm): 85.0 & Engine VIN: L & Fuel: GAS); 2000-2005 Toyota Celica (Aspiration: Naturally Aspirated & Engine Designation: 2ZZGE & Cylinder Head: DOHC & Liter: 1.8 & Engine(cc): 1795 & Cylinder: 4 & Block: L & Bore(in): 3.23 & Bore(mm): 82.0 & Stroke(in): 3.35 & Stroke(mm): 85.0 & Fuel: GAS); 2005-2006 Toyota Corolla (Aspiration: Naturally Aspirated & Engine Designation: 2ZZGE & Cylinder Head: DOHC & Liter: 1.8 & Engine(cc): 1795 & Cylinder: 4 & Block: L & Bore(in): 3.23 & Bore(mm): 82.0 & Stroke(in): 3.35 & Stroke(mm): 85.0 & Fuel: GAS); 2003-2006 Toyota Matrix (Aspiration: Naturally Aspirated & Engine Designation: 2ZZGE & Cylinder Head: DOHC & Liter: 1.8 & Engine(cc): 1795 & Cylinder: 4 & Block: L & Bore(in): 3.23 & Bore(mm): 82.0 & Stroke(in): 3.35 & Stroke(mm): 85.0 & Fuel: GAS); 2005-2011 Lotus Elise (Aspiration: Naturally Aspirated, Supercharged & Engine Designation: 2ZZGE & Cylinder Head: DOHC & Liter: 1.8 & Engine(cc): 1795 & Cylinder: 4 & Block: L & Bore(in): 3.23 & Bore(mm): 82.0 & Stroke(in): 3.35 & Stroke(mm): 85.0 & Fuel: GAS); 2005-2011 Lotus Exige (Aspiration: Naturally Aspirated, Supercharged & Engine Designation: 2ZZGE & Cylinder Head: DOHC & Liter: 1.8 & Engine(cc): 1795 & Cylinder: 4 & Block: L & Bore(in): 3.23 & Bore(mm): 82.0 & Stroke(in): 3.35 & Stroke(mm): 85.0 & Fuel: GAS)
