ACL Subaru EJ20/EJ22/EJ25 (For Thrust #5) Standard Size High Performance w/ Extra Oil - CT-1 Coated 5M8309HXC-STD

Main Bearing set 5 - standard coated with extra .025mm/.001" oil clearance

ACL RACE Series performance engine bearings are recognized as a premier brand throughout the motorsports world. RACE Series rod and main bearings are standard components in Race engines that have set records and won championships from Mexico to Bonneville - from sport compact drift racing to small block NASCAR, IHRA and NHRA cmpetitions. The unique combination of design, metallurgy and engineering provides RACE Series performance bearings with the endurance and capability to perform where others cannot. These exceptional bearings are available for a variety of American, Asian and European performance engines

ADDITIONAL INFORMATION

ACL Subaru EJ20/EJ22/EJ25 (For Thrust #5) Standard Size High Performance w/ Extra Oil - CT-1 Coated

Grade Type: Performance
Max Wall: 0.0784 IN
Max Wall: 1.992 MM
Outside Diameter: 64 MM
Outside Diameter: 2.5205 IN
Outside Diameter: 64.02 MM
Outside Diameter: 2.5197 IN
Shaft Diameter: 2.3622 IN
Shaft Diameter: 59.984 MM
Shaft Diameter: 2.3616 IN
Shaft Diameter: 60 MM
Width: 0.902 IN
Width: 22.92 MM

Interchange: Clevite MS2258HX

FITMENT NOTES

1998-2004 Subaru Forester (Aspiration: Naturally Aspirated & Engine Designation: EJ25D, EJ251 & Cylinder Head: DOHC, SOHC & Liter: 2.5 & Engine(cc): 2458 & Cylinder: 4 & Block: H & Bore(in): 3.92 & Bore(mm): 99.5 & Stroke(in): 3.11 & Stroke(mm): 79.0 & Engine VIN: 6 & Fuel: GAS); 1995-2005 Subaru Impreza (Aspiration: Naturally Aspirated, Turbocharged & Engine Designation: EJ22E, EJ22EZ, EJ25D, EJ251, EJ205 & Cylinder Head: SOHC, DOHC & Liter: 2.2, 2.5, 2.0 & Engine(cc): 2212, 2458, 1994 & Cylinder: 4 & Block: H & Bore(in): 3.82, 3.92, 3.62 & Bore(mm): 96.9, 99.5, 92.0 & Stroke(in): 2.95, 3.11 & Stroke(mm): 75.0, 79.0 & Engine VIN: 6, 4 & Fuel: GAS); 1991-2000 Subaru Legacy (Aspiration: Turbocharged, Naturally Aspirated & Engine Designation: EJ22EZ, EJ22E, EJ25D, EJ251 & Cylinder Head: SOHC, DOHC & Liter: 2.2, 2.5 & Engine(cc): 2212, 2458 & Cylinder: 4 & Block: H & Bore(in): 3.82, 3.92 & Bore(mm): 96.9, 99.5 & Stroke(in): 2.95, 3.11 & Stroke(mm): 75.0, 79.0 & Engine VIN: 6, 4, 3 & Fuel: GAS); 2000 Subaru Outback (Aspiration: Naturally Aspirated & Engine Designation: EJ251 & Cylinder Head: SOHC & Liter: 2.5 & Engine(cc): 2458 & Cylinder: 4 & Block: H & Bore(in): 3.92 & Bore(mm): 99.5 & Stroke(in): 3.11 & Stroke(mm): 79.0 & Fuel: GAS); 2005 Saab 9-2X (Aspiration: Turbocharged & Engine Designation: EJ205 & Cylinder Head: DOHC & Liter: 2.0 & Engine(cc): 1994 & Cylinder: 4 & Block: H & Bore(in): 3.62 & Bore(mm): 92.0 & Stroke(in): 2.95 & Stroke(mm): 75.0 & Fuel: GAS)
