ACL Toyota 2AZFE (2.4L) Standard Size High Performance Rod Bearing Set 4B8411H-STD

Connecting Rod Bearing Set 4

ACL RACE Series performance engine bearings are recognized as a premier brand throughout the motorsports world. RACE Series rod and main bearings are standard components in Race engines that have set records and won championships from Mexico to Bonneville - from sport compact drift racing to small block NASCAR, IHRA and NHRA cmpetitions. The unique combination of design, metallurgy and engineering provides RACE Series performance bearings with the endurance and capability to perform where others cannot. These exceptional bearings are available for a variety of American, Asian and European performance engines

ADDITIONAL INFORMATION

ACL Toyota 2AZFE (2.4L) Standard Size High Performance Rod Bearing Set

Grade Type: Performance
Max Wall: 1.49 MM
Max Wall: 0.0587 IN
Outside Diameter: 51.02 MM
Outside Diameter: 2.0087 IN
Outside Diameter: 51 MM
Outside Diameter: 2.0079 IN
Shaft Diameter: 48 MM
Shaft Diameter: 1.8898 IN
Shaft Diameter: 47.99 MM
Shaft Diameter: 1.8894 IN
Width: 0.614 IN
Width: 15.6 MM

FITMENT NOTES

2010-2012 Lexus HS250h Premium Base Ultra Premium (Engine Designation: 2AZ-FXE); 2001-2007 Toyota Highlander Base (Engine Designation: 2AZ-FE); 2002-2011 Toyota Camry XLE SE LE Base Hybrid CE (Engine Designation: 2AZ-FE, 2AZ-FXE); 2009-2013 Toyota Corolla XRS (Engine Designation: 2AZ-FE); 2009-2013 Toyota Matrix S XRS XR AWD (Engine Designation: 2AZ-FE); 2002-2008 Toyota Solara SE SLE SE Sport Sport (Engine Designation: 2AZ-FE); 2001-2008 Toyota RAV4 Base L Sport Limited (Engine Designation: 1AZ-FE, 2AZ-FE); 2008-2015 Scion xB Base (Engine Designation: 2AZ-FE); 2005-2010 Scion tC Base Spec (Engine Designation: 2AZ-FE)
