ACL Ford Prod V8 255/289/302 Standard Size Race Rod Bearing Set 8B634H-STD

8B634H-STD
Limited Supply: only 3 remaining
Availability: Item usually ships within 24 hours
Was: $90.05
Sale: $78.91
Save: 12%
Save: $11.14
Qty:
Free Shipping!

Description

Connecting Rod Bearing Set 8 standard

ACL RACE Series performance engine bearings are recognized as a premier brand throughout the motorsports world. RACE Series rod and main bearings are standard components in Race engines that have set records and won championships from Mexico to Bonneville - from sport compact drift racing to small block NASCAR, IHRA and NHRA cmpetitions. The unique combination of design, metallurgy and engineering provides RACE Series performance bearings with the endurance and capability to perform where others cannot. These exceptional bearings are available for a variety of American, Asian and European performance engines

ADDITIONAL INFORMATION

ACL Ford Prod V8 255/289/302 Standard Size Race Rod Bearing Set

Grade Type: Performance
Max Wall: 1.46 MM
Max Wall: 0.0575 IN
Outside Diameter: 56.891 MM
Outside Diameter: 2.2398 IN
Outside Diameter: 56.871 MM
Outside Diameter: 2.239 IN
Shaft Diameter: 53.939 MM
Shaft Diameter: 2.1236 IN
Shaft Diameter: 53.919 MM
Shaft Diameter: 2.1228 IN
Width: 0.726 IN
Width: 18.44 MM

Interchange: Clevite CB634HN

FITMENT NOTES

1967-1968 Omega Omega; 1962-1968 Shelby Cobra; 1962-1968 AC Shelby Cobra; 1964-1966 TVR Griffith; 1967-1968 TVR Tuscan; 1964-1965 Griffith 200; 1962-1967 Ford Country Sedan; 1962-1967 Ford Fairlane; 1962-1968 Ford Falcon; 1962-1965 Ford Falcon Sedan Delivery; 1963-1967 Ford Galaxie; 1962-1964 Ford Galaxie 500; 1962-1967 Ford Ranch Wagon; 1963 Ford 300; 1964-1967 Ford Custom; 1964-1969 Ford GT40; 1966-1968 Ford Bronco; 1962-1967 Ford Country Squire; 1965-1967 Ford LTD; 1964-1968 Ford Mustang; 1962-1967 Ford Ranchero; 1963-1964 Ford Sprint; 1964-1967 Mercury Caliente; 1967 Mercury Commuter; 1963 Mercury Country Cruiser; 1964-1968 Mercury Cyclone; 1966-1967 Mercury Voyager; 1962-1967 Mercury Villager; 1966-1967 Mercury Capri; 1962-1968 Mercury Comet; 1967-1968 Mercury Cougar; 1962-1963 Mercury Meteor; 1968 Mercury Montego; 1964-1967 Sunbeam Tiger

Compatible Vehicles

Details

Shipping Information

  • Item Requires Shipping
  • 0.3 lbs.
  • W2.7600” x H1.0200” x L6.3000”
