ACL Chevrolet V8 6.2L LT1/LT4/L86 (Gen V) Race Series Standard Size Rod Bearing Set 8B7281HX-STD

Connecting Rod Bearing Set 8 - Extra .025mm / 0.001" oil clearance - Standard crankshaft journal diameter

ACL RACE Series performance engine bearings are recognized as a premier brand throughout the motorsports world. RACE Series rod and main bearings are standard components in Race engines that have set records and won championships from Mexico to Bonneville - from sport compact drift racing to small block NASCAR, IHRA and NHRA cmpetitions. The unique combination of design, metallurgy and engineering provides RACE Series performance bearings with the endurance and capability to perform where others cannot. These exceptional bearings are available for a variety of American, Asian and European performance engines

ADDITIONAL INFORMATION

ACL Chevrolet V8 6.2L LT1/LT4/L86 (Gen V) Race Series Standard Size Rod Bearing Set

Grade Type: Performance
Max Wall: 1.559 MM
Max Wall: 0.0614 IN
Outside Diameter: 56.515 MM
Outside Diameter: 2.225 IN
Outside Diameter: 56.49 MM
Outside Diameter: 2.224 IN
Shaft Diameter: 53.335 MM
Shaft Diameter: 2.0998 IN
Shaft Diameter: 53.32 MM
Shaft Diameter: 2.0992 IN
Width: 0.837 IN
Width: 21.25 MM

FITMENT NOTES

2016-2024 Chevrolet Camaro (Aspiration: Naturally Aspirated & Engine Designation: LT1 & Cylinder Head: OHV & Liter: 6.2 & Engine(cc): 6162 & Engine(ci): 376 & Cylinder: 8 & Block: V & Bore(in): 4.06 & Bore(mm): 103.2 & Stroke(in): 3.62 & Stroke(mm): 92.0 & Engine VIN: 7 & Valves: 16 & Fuel: GAS); 2014-2019 Chevrolet Corvette (Aspiration: Naturally Aspirated & Engine Designation: LT1 & Cylinder Head: OHV & Liter: 6.2 & Engine(cc): 6162 & Engine(ci): 376 & Cylinder: 8 & Block: V & Bore(in): 4.06 & Bore(mm): 103.2 & Stroke(in): 3.62 & Stroke(mm): 92.0 & Engine VIN: 7 & Valves: 16 & Fuel: GAS)
