ACL 03+ Ford/Mazda 4 2.0L/2.3L DOHC Duratec Standard Size Race Series Main Bearing Set 5M8174HX-STD

Main Bearing set 5 - Standard Size with extra .025mm / 0.001" oil clearance (thinner)

ACL RACE Series performance engine bearings are recognized as a premier brand throughout the motorsports world. RACE Series rod and main bearings are standard components in Race engines that have set records and won championships from Mexico to Bonneville - from sport compact drift racing to small block NASCAR, IHRA and NHRA cmpetitions. The unique combination of design, metallurgy and engineering provides RACE Series performance bearings with the endurance and capability to perform where others cannot. These exceptional bearings are available for a variety of American, Asian and European performance engines

ADDITIONAL INFORMATION

ACL 03+ Ford/Mazda 4 2.0L/2.3L DOHC Duratec Standard Size Race Series Main Bearing Set

Grade Type: Performance
Max Wall: 2.491 MM
Max Wall: 0.0981 IN
Outside Diameter: 57.037 MM
Outside Diameter: 2.2456 IN
Outside Diameter: 57.019 MM
Outside Diameter: 2.2448 IN
Shaft Diameter: 52 MM
Shaft Diameter: 2.0472 IN
Shaft Diameter: 51.98 MM
Shaft Diameter: 2.0465 IN
Width: 19.1 MM
Width: 0.752 IN

FITMENT NOTES

2003 Ford Focus ZX3 (Aspiration: Naturally Aspirated & Cylinder Head: DOHC & Liter: 2.3 & Engine(ci): 140 & Cylinder: 4 & Block: L & Bore(in): 3.44 & Bore(mm): 87.4 & Stroke(in): 3.70 & Stroke(mm): 94.0 & Engine VIN: Z & Valves: 16 & Fuel: GAS & Engine Version: Duratec)
