ACL Toyota 3SGTE Standard Size High Performance w/ Extra Oil Clearance Main Bearing Set 5M8361HX-STD

Main Bearing set 5 - Standard Size with extra .025mm (0.001") oil clearance (thinner)

ACL RACE Series performance engine bearings are recognized as a premier brand throughout the motorsports world. RACE Series rod and main bearings are standard components in Race engines that have set records and won championships from Mexico to Bonneville - from sport compact drift racing to small block NASCAR, IHRA and NHRA cmpetitions. The unique combination of design, metallurgy and engineering provides RACE Series performance bearings with the endurance and capability to perform where others cannot. These exceptional bearings are available for a variety of American, Asian and European performance engines

ADDITIONAL INFORMATION

ACL Toyota 3SGTE Standard Size High Performance w/ Extra Oil Clearance Main Bearing Set

Grade Type: Performance
Max Wall: 0.0782 IN
Max Wall: 1.987 MM
Outside Diameter: 2.3236 IN
Outside Diameter: 59.038 MM
Outside Diameter: 2.3243 IN
Outside Diameter: 59.02 MM
Shaft Diameter: 2.1648 IN
Shaft Diameter: 54.985 MM
Shaft Diameter: 2.1654 IN
Shaft Diameter: 55 MM
Width: 19.2 MM
Width: 0.756 IN

FITMENT NOTES

1983-2001 Toyota Camry (Aspiration: Naturally Aspirated & Engine Designation: 2S-ELC, 3S-FE, 5S-FE & Cylinder Head: SOHC, DOHC & Liter: 2.0, 2.2 & Engine(cc): 1997, 1998, 2164 & Engine(ci): 122 & Cylinder: 4 & Block: L & Bore(in): 3.39, 3.43 & Bore(mm): 84.0, 86.0, 87.0 & Stroke(in): 3.54, 3.39, 3.58 & Stroke(mm): 90.0, 86.0, 91.0 & Engine VIN: S, G & Fuel: GAS); 1986-1999 Toyota Celica (Aspiration: Naturally Aspirated, Turbocharged & Engine Designation: 3S-GELC, 2S-ELC, 3S-FE, 3S-GTE, 5S-FE & Cylinder Head: DOHC, SOHC & Liter: 2.0, 2.2 & Engine(cc): 1998, 1997, 2164 & Engine(ci): 122 & Cylinder: 4 & Block: L & Bore(in): 3.39, 3.43 & Bore(mm): 86.0, 84.0, 87.0 & Stroke(in): 3.39, 3.54, 3.58 & Stroke(mm): 86.0, 90.0, 91.0 & Engine VIN: S, G & Fuel: GAS); 1991-1995 Toyota MR2 (Aspiration: Turbocharged, Naturally Aspirated & Engine Designation: 3S-GTE, 5S-FE & Cylinder Head: DOHC & Liter: 2.0, 2.2 & Engine(cc): 1998, 2164 & Engine(ci): 122 & Cylinder: 4 & Block: L & Bore(in): 3.39, 3.43 & Bore(mm): 86.0, 87.0 & Stroke(in): 3.39, 3.58 & Stroke(mm): 86.0, 91.0 & Engine VIN: S & Fuel: GAS); 1999-2001 Toyota Solara (Aspiration: Naturally Aspirated & Engine Designation: 5S-FE & Cylinder Head: DOHC & Liter: 2.2 & Engine(cc): 2164 & Cylinder: 4 & Block: L & Bore(in): 3.43 & Bore(mm): 87.0 & Stroke(in): 3.58 & Stroke(mm): 91.0 & Engine VIN: G & Fuel: GAS); 1996-2000 Toyota RAV4 (Aspiration: Naturally Aspirated & Engine Designation: 3S-FE & Cylinder Head: DOHC & Liter: 2.0 & Engine(cc): 1998 & Engine(ci): 122 & Cylinder: 4 & Block: L & Bore(in): 3.39 & Bore(mm): 86.0 & Stroke(in): 3.39 & Stroke(mm): 86.0 & Engine VIN: P & Fuel: GAS)
