ACL Chevy V8 LT1/LT4/L86 Race Series .010 Oversized High Performance Main Bearing Set 5M7292H-010

Main Bearing set 5 - .25mm / 0.010" undersize

ACL RACE Series performance engine bearings are recognized as a premier brand throughout the motorsports world. RACE Series rod and main bearings are standard components in Race engines that have set records and won championships from Mexico to Bonneville - from sport compact drift racing to small block NASCAR, IHRA and NHRA cmpetitions. The unique combination of design, metallurgy and engineering provides RACE Series performance bearings with the endurance and capability to perform where others cannot. These exceptional bearings are available for a variety of American, Asian and European performance engines

ADDITIONAL INFORMATION

ACL Chevy V8 LT1/LT4/L86 Race Series .010 Oversized High Performance Main Bearing Set

Grade Type: Performance
Max Wall: 2.43 MM
Max Wall: 0.0957 IN
Outside Diameter: 69.887 MM
Outside Diameter: 2.7515 IN
Outside Diameter: 69.873 MM
Outside Diameter: 2.7509 IN
Shaft Diameter: 65.007 MM
Shaft Diameter: 2.5593 IN
Shaft Diameter: 64.993 MM
Shaft Diameter: 2.5588 IN
Width: 26.1 MM
Width: 1.028 IN

Interchange: Clevite MS-2339H

FITMENT NOTES

2016-2024 Chevrolet Camaro (Aspiration: Naturally Aspirated & Engine Designation: LT1 & Cylinder Head: OHV & Liter: 6.2 & Engine(cc): 6162 & Engine(ci): 376 & Cylinder: 8 & Block: V & Bore(in): 4.06 & Bore(mm): 103.2 & Stroke(in): 3.62 & Stroke(mm): 92.0 & Engine VIN: 7 & Valves: 16 & Fuel: GAS); 2014-2019 Chevrolet Corvette (Aspiration: Naturally Aspirated & Engine Designation: LT1 & Cylinder Head: OHV & Liter: 6.2 & Engine(cc): 6162 & Engine(ci): 376 & Cylinder: 8 & Block: V & Bore(in): 4.06 & Bore(mm): 103.2 & Stroke(in): 3.62 & Stroke(mm): 92.0 & Engine VIN: 7 & Valves: 16 & Fuel: GAS)
