ACL BMW S85B50 5.0L V10 Standard Size (w/.001in Oil Clearance) Performance Rod Bearing Set 10B1580HX-STD

Connecting Rod Bearing Set 10 - Standard with extra .025mm (0.001") oil clearance (thinner)

ACL RACE Series performance engine bearings are recognized as a premier brand throughout the motorsports world. RACE Series rod and main bearings are standard components in Race engines that have set records and won championships from Mexico to Bonneville - from sport compact drift racing to small block NASCAR, IHRA and NHRA cmpetitions. The unique combination of design, metallurgy and engineering provides RACE Series performance bearings with the endurance and capability to perform where others cannot. These exceptional bearings are available for a variety of American, Asian and European performance engines

ADDITIONAL INFORMATION

ACL BMW S85B50 5.0L V10 Standard Size (w/.001in Oil Clearance) Performance Rod Bearing Set

Grade Type: Performance
Max Wall: 1.985 MM
Max Wall: 0.0781 IN
Outside Diameter: 56.013 MM
Outside Diameter: 2.2052 IN
Outside Diameter: 56 MM
Outside Diameter: 2.2047 IN
Shaft Diameter: 51.991 MM
Shaft Diameter: 2.0469 IN
Shaft Diameter: 51.975 MM
Shaft Diameter: 2.0463 IN
Width: 0.626 IN
Width: 15.9 MM

FITMENT NOTES

2006-2010 BMW M5 (Aspiration: Naturally Aspirated & Engine Designation: S85B50A & Cylinder Head: DOHC & Liter: 5.0 & Engine(cc): 4999 & Cylinder: 10 & Block: V & Bore(in): 3.62 & Bore(mm): 92.0 & Stroke(in): 2.96 & Stroke(mm): 75.2 & Fuel: GAS); 2006-2011 BMW M6 (Aspiration: Naturally Aspirated & Engine Designation: S85B50A, S85B50 & Cylinder Head: DOHC & Liter: 5.0 & Engine(cc): 4999 & Engine(ci): 305 & Cylinder: 10 & Block: V & Bore(in): 3.62 & Bore(mm): 92.0 & Stroke(in): 2.96 & Stroke(mm): 75.2 & Fuel: GAS)
