ACL Toyota/Lexus 2JZGE/2JZGTE 3.0L Std Size High Perf w/ Extra Oil Clearance Rod Bearing CT-1 Coated 6B8100HXC-STD

Connecting Rod Bearing Set 6 - standard coated with extra .025mm/.001" oil clearance

ACL RACE Series performance engine bearings are recognized as a premier brand throughout the motorsports world. RACE Series rod and main bearings are standard components in Race engines that have set records and won championships from Mexico to Bonneville - from sport compact drift racing to small block NASCAR, IHRA and NHRA cmpetitions. The unique combination of design, metallurgy and engineering provides RACE Series performance bearings with the endurance and capability to perform where others cannot. These exceptional bearings are available for a variety of American, Asian and European performance engines

ADDITIONAL INFORMATION

ACL Toyota/Lexus 2JZGE/2JZGTE 3.0L Std Size High Perf w/ Extra Oil Clearance Rod Bearing CT-1 Coated

Grade Type: Performance
Max Wall: 1.493 MM
Max Wall: 0.0588 IN
Outside Diameter: 55.042 MM
Outside Diameter: 2.1663 IN
Outside Diameter: 2.167 IN
Outside Diameter: 55.024 MM
Shaft Diameter: 51.981 MM
Shaft Diameter: 52 MM
Shaft Diameter: 2.0472 IN
Shaft Diameter: 2.0465 IN
Width: 19.3 MM
Width: 0.76 IN

Interchange: Clevite CB1628HX

FITMENT NOTES

2001-2005 Lexus IS300 (Aspiration: Naturally Aspirated & Engine Designation: 2JZ-GE & Cylinder Head: DOHC & Liter: 3.0 & Engine(cc): 2997 & Cylinder: 6 & Block: L & Bore(in): 3.39 & Bore(mm): 86.0 & Stroke(in): 3.39 & Stroke(mm): 86.0 & Fuel: GAS); 1992-2000 Lexus SC300 (Aspiration: Naturally Aspirated & Engine Designation: 2JZ-GE & Cylinder Head: DOHC & Liter: 3.0 & Engine(cc): 2997 & Cylinder: 6 & Block: L & Bore(in): 3.39 & Bore(mm): 86.0 & Stroke(in): 3.39 & Stroke(mm): 86.0 & Engine VIN: J, D & Fuel: GAS); 1993-2005 Lexus GS300 (Aspiration: Naturally Aspirated & Engine Designation: 2JZ-GE & Cylinder Head: DOHC & Liter: 3.0 & Engine(cc): 2997 & Cylinder: 6 & Block: L & Bore(in): 3.39 & Bore(mm): 86.0 & Stroke(in): 3.39 & Stroke(mm): 86.0 & Engine VIN: J, D & Fuel: GAS); 1993-1998 Toyota Supra (Aspiration: Naturally Aspirated, Turbocharged & Engine Designation: 2JZ-GE, 2JZ-GTE & Cylinder Head: DOHC & Liter: 3.0 & Engine(cc): 2997 & Cylinder: 6 & Block: L & Bore(in): 3.39 & Bore(mm): 86.0 & Stroke(in): 3.39 & Stroke(mm): 86.0 & Engine VIN: J, E, D & Fuel: GAS)
