ACL Ford 4 2.0L Duratec Standard Size Race Series Rod Bearing Set 4B4390H-STD

Connecting Rod Bearing Set 4 - Standard Size

ACL RACE Series performance engine bearings are recognized as a premier brand throughout the motorsports world. RACE Series rod and main bearings are standard components in Race engines that have set records and won championships from Mexico to Bonneville - from sport compact drift racing to small block NASCAR, IHRA and NHRA cmpetitions. The unique combination of design, metallurgy and engineering provides RACE Series performance bearings with the endurance and capability to perform where others cannot. These exceptional bearings are available for a variety of American, Asian and European performance engines

ADDITIONAL INFORMATION

ACL Ford 4 2.0L Duratec Standard Size Race Series Rod Bearing Set

Grade Type: Performance
Max Wall: 1.503 MM
Max Wall: 0.0592 IN
Outside Diameter: 50.045 MM
Outside Diameter: 1.9695 IN
Outside Diameter: 50.025 MM
Outside Diameter: 1.9703 IN
Shaft Diameter: 47 MM
Shaft Diameter: 1.8504 IN
Shaft Diameter: 46.98 MM
Shaft Diameter: 1.8496 IN
Width: 0.6398 IN
Width: 16.25 MM

Interchange: Clevite CB-1840H

FITMENT NOTES

2005-2006 Ford Focus ZX3 (Aspiration: Naturally Aspirated & Cylinder Head: DOHC & Liter: 2.0 & Engine(cc): 1999 & Engine(ci): 122 & Cylinder: 4 & Block: L & Bore(in): 3.44 & Bore(mm): 87.5 & Stroke(in): 3.27 & Stroke(mm): 83.1 & Engine VIN: N & Fuel: GAS & Engine Version: Duratec); 2004-2013 Mazda 3 (Aspiration: Naturally Aspirated & Cylinder Head: DOHC & Liter: 2.0 & Engine(cc): 2000 & Engine(ci): 122 & Cylinder: 4 & Block: L & Bore(in): 3.44 & Bore(mm): 87.5 & Stroke(in): 3.27 & Stroke(mm): 83.1 & Valves: 16 & Fuel: GAS)
