ACL Acura B17A1/B18A1/B18B1 0.25mm Overzized High Performance Rod Bearing Set 4B1946H-.25

Connecting Rod Bearing Set 4 - .25mm (0.010") undersize

ACL RACE Series performance engine bearings are recognized as a premier brand throughout the motorsports world. RACE Series rod and main bearings are standard components in Race engines that have set records and won championships from Mexico to Bonneville - from sport compact drift racing to small block NASCAR, IHRA and NHRA cmpetitions. The unique combination of design, metallurgy and engineering provides RACE Series performance bearings with the endurance and capability to perform where others cannot. These exceptional bearings are available for a variety of American, Asian and European performance engines

ADDITIONAL INFORMATION

ACL Acura B17A1/B18A1/B18B1 0.25mm Overzized High Performance Rod Bearing Set

Grade Type: Performance
Max Wall: 1.504 MM
Max Wall: 0.0592 IN
Outside Diameter: 48.024 MM
Outside Diameter: 1.8907 IN
Outside Diameter: 48 MM
Outside Diameter: 1.8898 IN
Shaft Diameter: 45 MM
Shaft Diameter: 1.7717 IN
Shaft Diameter: 44.98 MM
Shaft Diameter: 1.7709 IN
Width: 0.768 IN
Width: 19.5 MM

Interchange: Clevite CB-1353H

FITMENT NOTES

1990-2001 Acura Integra (Aspiration: Naturally Aspirated & Engine Designation: B18A1, B17A1, B18B1 & Cylinder Head: DOHC & Liter: 1.8, 1.7 & Engine(cc): 1834, 1678 & Cylinder: 4 & Block: L & Bore(in): 3.19 & Bore(mm): 81.0 & Stroke(mm): 88.8, 81.3 & Fuel: GAS & Engine Version: VTEC); 1984-1985 Honda Accord (Aspiration: Naturally Aspirated & Engine Designation: ES2 & Cylinder Head: SOHC & Liter: 1.8 & Engine(cc): 1829 & Cylinder: 4 & Block: L & Bore(in): 3.15 & Bore(mm): 80.0 & Stroke(in): 3.58 & Stroke(mm): 91.0 & Fuel: GAS); 1997-2001 Honda CR-V (Aspiration: Naturally Aspirated & Engine Designation: B20B4, B20Z2 & Cylinder Head: DOHC & Liter: 2.0 & Engine(cc): 1972 & Cylinder: 4 & Block: L & Bore(in): 3.31 & Bore(mm): 84.0 & Stroke(mm): 88.8 & Fuel: GAS); 1988-1990 Honda Prelude (Aspiration: Naturally Aspirated & Cylinder Head: SOHC & Liter: 2.0 & Engine(cc): 1958 & Cylinder: 4 & Block: L & Bore(in): 3.19 & Bore(mm): 81.0 & Stroke(in): 3.74 & Stroke(mm): 95.0 & Fuel: GAS)
