ACL Mitsubishi 4G63/4G64 7 Bolt 2nd Gen DSM and EVO I-IV Standard Size High Performance w/ Extra Oil 5M1186HX-STD

Main Bearing Set 5 - Standard Size with extra .025mm (0.001") oil clearance (thinner)

ACL RACE Series performance engine bearings are recognized as a premier brand throughout the motorsports world. RACE Series rod and main bearings are standard components in Race engines that have set records and won championships from Mexico to Bonneville - from sport compact drift racing to small block NASCAR, IHRA and NHRA cmpetitions. The unique combination of design, metallurgy and engineering provides RACE Series performance bearings with the endurance and capability to perform where others cannot. These exceptional bearings are available for a variety of American, Asian and European performance engines

ADDITIONAL INFORMATION

ACL Mitsubishi 4G63/4G64 7 Bolt 2nd Gen DSM and EVO I-IV Standard Size High Performance w/ Extra Oil

Grade Type: Performance
Max Wall: 1.977 MM
Max Wall: 0.0778 IN
Outside Diameter: 61.021 MM
Outside Diameter: 2.4024 IN
Outside Diameter: 61 MM
Outside Diameter: 2.4016 IN
Shaft Diameter: 57 MM
Shaft Diameter: 2.2441 IN
Shaft Diameter: 56.985 MM
Shaft Diameter: 2.2435 IN
Width: 20.63 MM
Width: 0.812 IN

Interchange: Clevite MS-2039HX

FITMENT NOTES

1993-1994 Dodge Colt; 1993-1996 Eagle Summit; 2005-2006 Mitsubishi Lancer; 1994-2003 Mitsubishi Galant; 1995-2005 Mitsubishi Eclipse; 1993-1995 Mitsubishi Expo; 1993-1994 Mitsubishi Expo LRV; 1997-1999 Mitsubishi Montero Sport
