ACL Honda F20C/F22C / 97-01 H22A4 0.25mm Oversized High Performance Rod Bearing Set 4B1912H-.25

Connecting Rod Bearing Set 4 - .25mm (0.010") undersize

ACL RACE Series performance engine bearings are recognized as a premier brand throughout the motorsports world. RACE Series rod and main bearings are standard components in Race engines that have set records and won championships from Mexico to Bonneville - from sport compact drift racing to small block NASCAR, IHRA and NHRA cmpetitions. The unique combination of design, metallurgy and engineering provides RACE Series performance bearings with the endurance and capability to perform where others cannot. These exceptional bearings are available for a variety of American, Asian and European performance engines

ADDITIONAL INFORMATION

ACL Honda F20C/F22C / 97-01 H22A4 0.25mm Oversized High Performance Rod Bearing Set

Grade Type: Performance
Max Wall: 1.496 MM
Max Wall: 0.0589 IN
Outside Diameter: 51.024 MM
Outside Diameter: 2.0088 IN
Outside Diameter: 51.004 MM
Outside Diameter: 2.008 IN
Shaft Diameter: 48 MM
Shaft Diameter: 1.8898 IN
Shaft Diameter: 47.98 MM
Shaft Diameter: 1.889 IN
Width: 0.764 IN
Width: 19.4 MM

Interchange: Clevite CB1780H

FITMENT NOTES

1997-2001 Honda Prelude (Aspiration: Naturally Aspirated & Engine Designation: H22A4 & Cylinder Head: DOHC & Liter: 2.2 & Engine(cc): 2156 & Cylinder: 4 & Block: L & Bore(in): 3.43 & Bore(mm): 87.0 & Stroke(in): 3.57 & Stroke(mm): 90.7 & Fuel: GAS & Engine Version: VTEC); 2000-2009 Honda S2000 (Aspiration: Naturally Aspirated & Engine Designation: F20C1, F22C1 & Cylinder Head: DOHC & Liter: 2.0, 2.2 & Engine(cc): 1997, 2157 & Cylinder: 4 & Block: L & Bore(in): 3.42, 3.43 & Bore(mm): 87.0 & Stroke(in): 3.31, 3.57 & Stroke(mm): 84.0, 90.7 & Fuel: GAS & Engine Version: VTEC)
