ACL BMW N20B20 / N26B20 2.0L Inline Race Series Standard Size Conrod Rod Bearing Set 4B1584H-STD

Connecting Rod Bearing Set 4

ACL RACE Series performance engine bearings are recognized as a premier brand throughout the motorsports world. RACE Series rod and main bearings are standard components in Race engines that have set records and won championships from Mexico to Bonneville - from sport compact drift racing to small block NASCAR, IHRA and NHRA cmpetitions. The unique combination of design, metallurgy and engineering provides RACE Series performance bearings with the endurance and capability to perform where others cannot. These exceptional bearings are available for a variety of American, Asian and European performance engines

ADDITIONAL INFORMATION

ACL BMW N20B20 / N26B20 2.0L Inline Race Series Standard Size Conrod Rod Bearing Set

Grade Type: Performance
Max Wall: 1.793 MM
Max Wall: 0.0706 IN
Outside Diameter: 53.616 MM
Outside Diameter: 2.1109 IN
Outside Diameter: 53.6 MM
Outside Diameter: 2.1102 IN
Shaft Diameter: 49.993 MM
Shaft Diameter: 1.9682 IN
Shaft Diameter: 49.973 MM
Shaft Diameter: 1.9674 IN
Width: 0.691 IN
Width: 17.55 MM

FITMENT NOTES

2011-2013 BMW 325i Base M Sport Edition Exclusive (Engine Designation: N54B30); 2015-2018 BMW M3 Base (Engine Designation: S55B30); 2017 BMW M5 Competition Edition (Engine Designation: S55B30); 2015-2020 BMW M4 Base GTS CS (Engine Designation: S55B30); 2019-2021 BMW M2 Competition CS (Engine Designation: S55B30)
