ACL Ford/Mazda (L3) Duratec 2.3L Standard Size High Performance Rod Bearing Set 4B8170H-STD

Connecting Rod Bearing Set 4 - Standard Size

ACL RACE Series performance engine bearings are recognized as a premier brand throughout the motorsports world. RACE Series rod and main bearings are standard components in Race engines that have set records and won championships from Mexico to Bonneville - from sport compact drift racing to small block NASCAR, IHRA and NHRA cmpetitions. The unique combination of design, metallurgy and engineering provides RACE Series performance bearings with the endurance and capability to perform where others cannot. These exceptional bearings are available for a variety of American, Asian and European performance engines

ADDITIONAL INFORMATION

ACL Ford/Mazda (L3) Duratec 2.3L Standard Size High Performance Rod Bearing Set

Grade Type: Performance
Max Wall: 1.5 MM
Max Wall: 0.0591 IN
Outside Diameter: 53.045 MM
Outside Diameter: 2.0884 IN
Outside Diameter: 53.025 MM
Outside Diameter: 2.0876 IN
Shaft Diameter: 50 MM
Shaft Diameter: 1.9685 IN
Shaft Diameter: 49.98 MM
Shaft Diameter: 1.9677 IN
Width: 0.669 IN
Width: 17 MM

Interchange: Clevite CB1838H

FITMENT NOTES

2003-2008 Mazda 6 (Aspiration: Naturally Aspirated & Cylinder Head: DOHC & Liter: 2.3 & Engine(cc): 2260 & Cylinder: 4 & Block: L & Bore(in): 3.44 & Bore(mm): 87.4 & Stroke(in): 3.70 & Stroke(mm): 94.0 & Valves: 16 & Fuel: GAS); 2004-2009 Mazda 3 (Aspiration: Naturally Aspirated & Cylinder Head: DOHC & Liter: 2.3 & Engine(cc): 2260 & Cylinder: 4 & Block: L & Bore(in): 3.44 & Bore(mm): 87.4 & Stroke(in): 3.70 & Stroke(mm): 94.0 & Valves: 16 & Fuel: GAS)
