Baja Designs OnX6 Arc Series Driving Combo Pattern 30in LED Light Bar

Baja Designs OnX6 Arc Series Driving Combo Pattern 30in LED Light Bar

Associated Comments: One Light Bar
Amperage Rating (A): 21.7 (High); 17.1 (Low)
Average Rated Life (hr.): 49,930
Beam Pattern: Driving/Combo
Bezel Material: Billet Machined Aluminum
Brightness (Lumens): 32,070 (High); 25,610 (Low)
Depth (in.): 4.29
Description: Arc; Driving/Combo; Clear
Height (in.): 2.69
Housing Color: Black
Housing Material: Aircraft Grade Aluminum with Mil-Spec Hard Anodize
Length (in.): 30
Lens Color: Clear
Lens Material: Hardcoated Polycarbonate
Light Quantity: 1
Lighting Modes: High Beam/Low Beam
Lighting Quantity: 18
Lighting Technology: LED
Lighting Type: Forward Projecting
Mounting Hardware Description: Mounting Brackets
Mounting Hardware Included: Yes
Mounting Hardware Material: Stainless Steel
Overvoltage Protection: Built-In
Product Type: OnX6+ 30 Inch Arc LED Light Bar
Prop 65 (C, R or CR): CR
Prop 65 - Short Label: WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
Prop 65 Warning Label: Prop 65 WARNING: This product can expose you to chemicals, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Prop 65 Yes/No: Yes
Standards/Compliance (Durability): Exceeds MIL-STD810G (Mil-Spec Testing)
Standards/Compliance (Impact Resistance): IK10 Compliant (Mechanical Impact Testing)
Standards/Compliance (Water Resistance): IP69K (Waterproof up to 9ft & Pressure Washable)
Title: Baja Designs - 523003 - OnX6 Arc LED Light Bar
Universal or Specific: Universal
Wattage (W): 278 (High); 222 (Low)
Weight (lbs.): 11.45
Wiring Harness Description: Hi-Low Dongle
Wiring Harness Included: No
Add-On: Accessories-458412-Light Cover (Amber)
Add-On: Accessories-458410-Light Cover (Clear)
Add-On: Accessories-458411-Rock Guard (Black)
Add-On: Accessories-458117-Lens Kit (Driving/Combo; Amber)
Add-On: Accessories-458114-Lens Kit (Driving/Combo; Clear)
Add-On: Accessories-458113-Lens Kit (Spot; Clear)
Add-On: Accessories-458116-Lens Kit (Wide Cornering; Amber)
Add-On: Accessories-458115-Lens Kit (Wide Cornering; Clear)
Add-On: Associated Products-660302-Anti Theft Hardware Kit - 1/4-20x1/2 Socket Pin Head Bolts
Add-On: Associated Products-660303-Anti Theft Hardware Kit - 3/8 in. Tamperproof Nuts
Add-On: Compatible Products-613608-Harness Splitter
Add-On: Compatible Products-613609-Harness/Splitter (55 Inch)
Add-On: Compatible Products-640163-Harness/Splitter (Hi Beam)
Add-On: Compatible Products-640094-Upfitter Harness
Add-On: Compatible Products-640119-Wiring Harness (Hi/Low)
Add-On: Compatible Products-640115-Wiring Harness (On/Off)
