BMR 15-17 S550 Mustang Front & Rear Sway Bar Kit w/ Bushings - Red

BMR Suspension designed the SB043 sway bar kit for street performance, autocross, and road race applications.

The two primary functions of sway bars are to control body roll and to determine the understeer or oversteer behavior of a vehicle. Stock sway bars have low torsional spring rates because they are manufactured from small diameter bar stock or tubing. BMR Suspension?s SB043 front and rear sway bar kit was designed by factoring in the vehicle weight, application, motion ratio, coil spring rate, and adjustability requirements. Manufactured from heavy-duty 35mm (front) and 25mm (rear)DOM steel tubing, the SB043 is cold formed to better resist torsional fatigue and retain its "memory" far longer than the hot-formed bars used by many competitors. The sway bar is CNC-formed for exact manufacturing tolerances and repeatable high quality.Thrust washers are welded to the front bar to locate the sway bar bushing mounts. This is critical as it properly locates the sway bar and prevents lateral movement during hard cornering maneuvers The SB043 attaches to your S550 Mustang with polyurethane bushings, reducing the deflection from the stock rubber bushings. These bushings are molded from 88-durometer, low-deflection, polyurethane, and are internally fluted to keep grease in the bushing.

Fits all S550 Mustangs
Designed for street performance, autocross, and road race applications
Dramatically reduces body roll
19%-55% increase in sway bar rate (front), 63%-208% increase is sway bar rate (rear)
Cold formed to better resist torsional fatigue
Manufactured from 35mm heavy-wall DOM tubing (front), Manufactured from 25mm heavy-duty bar stock (rear)
Three-way adjustable for street and track use
Adjustability allows for fine-tuning of suspension; High durometer, greasable polyurethane bushings
Zinc-plated inner sleeves
Billet aluminum, black anodized bushings saddles
Durable powdercoat finish
3-4 hour installation time
Proudly designed in the U.S.A.
Proudly made in the U.S.A.

ADDITIONAL INFORMATION

BMR 15-17 S550 Mustang Front & Rear Sway Bar Kit w/ Bushings - Red

Front Sway Bar Adjustable: 3-position
Front Sway Bar Diameter (in): 1.375 inches
Front Sway Bar Diameter (mm): 35.0 mm
Front Sway Bar Type: Hollow
Mounting Hardware Included: Yes
Position: Front and rear
Quantity: Sold as a kit
Rear Sway Bar Adjustable: 3-position
Rear Sway Bar Diameter (in): 1.00 inches
Rear Sway Bar Diameter (mm): 25.0 mm
Rear Sway Bar Type: Hollow
Sway Bar Finish: Red powdercoated
Sway Bar Material: Steel
Title: BMR Suspension SB043R Sway Bar Kit With Bushings, Front (SB044), Rear (SB045)

FITMENT NOTES

2015-2020 Ford Mustang
