BMR 11-14 S197 Mustang Rear Hollow 25mm Adj. Sway Bar Kit w/ Bushings - Red

BMR Suspension designed the SB042 sway bar kit for street performance, autocross, and road race applications.

The two primary functions of sway bars are to control body roll and to determine the understeer or oversteer behavior of a vehicle. Stock sway bars have low torsional spring rates because they are manufactured from small diameter bar stock or tubing. BMR Suspension?s SB042 rear sway bar was designed by factoring in the vehicle weight, application, motion ratio, coil spring rate, and adjustability requirements. Manufactured from heavy-wall 25mm DOM tubing, the SB042 is cold formed to better resist torsional fatigue and retain its "memory" far longer than the hot-formed bars used by many competitors. The sway bar is CNC-formed for exact manufacturing tolerances and repeatable high quality. The SB042 attaches to your Mustang with fabricated end links and 88-durometer polyurethane bushings, reducing the deflection from the stock rubber bushings. These bushings are molded from 88-durometer, low-deflection, polyurethane, and are internally fluted to keeps grease in the bushing. The fabricated laser cut, TIG-welded steel sway bar end links are reinforced to minimize deflection. The sway bar is 4-way adjustable to tune the amount of torsional spring rate and to determine the handling characteristics (understeer/oversteer) of the vehicle.

Fits all S197 Mustangs
Designed for street performance, autocross, and road race applications
Dramatically reduces body roll
16%-270% increase is sway bar rate over stock sway bar (depending on year and model)
Cold formed to better resist torsional fatigue
Manufactured from 25mm heavy-wall DOM tubing for increased strength
Four-way adjustable for street and track use
Adjustability allows for fine-tuning of suspension
Fabricated sway bar end links
High-durometer, greasable polyurethane bushings
Zinc-plated inner sleeves
Durable powdercoat finish
1-2 hour installation time
Proudly designed in the U.S.A.
Proudly made in the U.S.A.
