RIGID Adapt E-Series LED Light Bar With 3 Lighting Zones And GPS Module, 50 Inch

RIGID Adapt E-Series LED Light Bar With 3 Lighting Zones And GPS Module, 50 Inch

The RIGID Adapt E-Series LED Light Bar features the same style and construction as RIGIDs legendary E-Series, from the high-strength aluminum heat sink to the unbreakable polycarbonate lens. On the inside, however, the Adapt E-Series contains cutting-edge technology. The Adapt E-Series takes off-road lighting performance to a whole new level with two layers of adaptive response to your vehicle and driving conditions.

Universal Fit, Fits All Existing E-Series Grilles and Mounts
Use In Adapt Mode Or All On
Limited Lifetime Warranty
Alloy Housing and Heatsink
Unbreakable Polycarbonate Lens
Pressure Equalizing Vent
Black Exposed Printed Circuit Board
Patented Optics
50,000 Hr+ LED Lifespan
Off Road Use Only
Harness, Switch & Relay Included
3 Optic Zones - Scene, Driving, Spot
Seamless Beam Transition
Slow Speed, Moderate Speed & High Speed Beam Patterns
9-36 VDC
Two Layers of Adaptive Response
Active Power Management System - Power Capacity Sensing
Active View Technology - Internal GPS Module

ADDITIONAL INFORMATION

Title: RIGID Adapt E-Series LED Light Bar With 3 Lighting Zones And GPS Module, 50 Inch
Associated Comments: Professional Installation Recommended, RIGID Adapt

A = LUX at 10 Meters: 9,398
Add-On: 11001, 11002, 11003, 11008, 46590, 1063, 1067, 1031, 30130, 30140, 30150
ASIN: No
B = Beam Distance with 1 LUX: 969
C = Beam Distance with .25 LUX: 1,939
Field Horizontal (Measured in Degrees): 17
Field Vertical (Measured in Degrees): 16
Number of LEDs: 112
Peak Beam Intensity (cd): 939,827
Product Family: Adapt
Product Fits What: Universal Fit
Product Weight: 13.84
Prop 65 Yes/No: No
Raw Lumens: 38,896
Size: 50 in.
Title: RIGID Adapt E-Series LED Light Bar With 3 Lighting Zones And GPS Module, 50 Inch
Watts: 358
What's In The Package: Stainless Steel Mounting Brackets, Hardware Kit, Wire Harness, Relay, Switch, Install Instructions
Zone 1 A: 53.62
Zone 1 Amp Draw: 6.3
Zone 1 B: 73.2
Zone 1 C: 146.5
Zone 1 Horizontal Field beam angle: 101.9
Zone 1 LED's count: 8
Zone 1 Peak CD: 5,362
Zone 1 Raw Lm: 8,641
Zone 1 Vertical Field beam angle: 96.5
Zone 1 Watts: 88
Zone 2 A: 2285.65
Zone 2 Amp Draw: 19.6
Zone 2 B: 478.1
Zone 2 C: 956.2
Zone 2 Horizontal Field beam angle: 51.1
Zone 2 LED's count: 52
Zone 2 Peak CD: 228,565
Zone 2 Raw Lm: 33,176
Zone 2 Vertical Field beam angle: 22.1
Zone 2 Watts: 274
Zone 3 A: 9398.27
Zone 3 Amp Draw: 25.6
Zone 3 B: 969.4
Zone 3 C: 1938.9
Zone 3 Horizontal Field beam angle: 17.7
Zone 3 LED's count: 52
Zone 3 Peak CD: 939,827
Zone 3 Raw Lm: 38,896
Zone 3 Vertical Field beam angle: 16.5
Zone 3 Watts: 358

FITMENT NOTES

Universal
