RIGID SR-Series 30 inch SAE Driving Amber

RIGID SR-Series 30 inch Dual Function SAE Auxilary High Beam Driving Lights with Amber Backlight

Off-road auxiliary lighting is one thing, but everyone knows that it's important to have lighting that is also safe and legal for on-road use. RIGID's SAE Compliant Fog Lights and Auxiliary High Beam Driving Lights allow them to be used on-the-road and not just off-road. RIGID created the proprietary output spread and height with the new patented Clarilux(TM) optic system. The color temperature of these LEDs was carefully chosen to be a perfect range of pure daylight to penetrate the night for superior clarity on the road. These SAE Compliant lights project long-range high intensity light while drawing very little power and provide up to 50,000 useful hours. As an added function, the SR-Series SAE compliant lights offer Amber backlighting. This feature can be ran independently, or in tandem with the forward projecting LEDs. The low profile design includes a High-Grade Aluminum Alloy Housing with a custom designed oversized heat sink to keep the LEDs running cooler, brighter and longer. Combine this with the strength of a polycarbonate lens; the RIGID SAE Compliant Lights represent the ultimate solution for your street-legal lighting in North America.

SAE J581 Compliant Street Legal Auxiliary High Beam LED Light
IP68 Rated - Dust/Water Ingress
Pressure Equalizing Vent
Patented Optics
Durable UV Polyester Powder Coat
50,000 Hour Lifespan
Operating Temp -40 Deg F To +145 Deg F
RoHS Compliant
Limited Lifetime Warranty
Legal For On Road and Off Road Use
Toggleable Amber Backlight
Multi-Function With RIGID Branding Plate
Integrated Thermal Management System
9-36 VDC Operation
RFI/EMI Protection
Impact Resistant Polycarbonate Lens
High Grade Alloy Housing And Heatsink
Over/Under Voltage Protection

ADDITIONAL INFORMATION

Title: RIGID Industries 930414 SR-Series 30 inch SAE Driving Amber
Associated Comments:

# of LED's: 48
A = LUX at 10 Meters: 745.5
Amp Draw: 12.9
B = Beam Distance with 1 LUX: 273
C = Beam Distance with .25 LUX: 546.1
Field Horizontal (Measured in Degrees): 53.6
Field Vertical (Measured in Degrees): 9.1
Lighting Family: SR-Series
Peak Beam Intensity (cd): 74,555
Product Family: Fog Lights
Product Fits What: Universal
Product Weight: 7.4
Prop 65 Yes/No: No
Raw Lumens: 14,148
Title: RIGID SR-Series 30 in Dual Function SAE Auxilary High Beam Driving Lights with Amber Backlight
Watts: 180
What's In The Package: SR-Series 30 Inch Dual Function SAE Auxiliary High Beam Driving Lights with Amber Backlight, two black powder coated L-shape brackets, mounting Hardware, wiring harness

FITMENT NOTES

Universal
