Bilstein 33-247823 SN2 Series - Suspension Shock Absorber

Bilstein 33-247823 SN2 Series - Suspension Shock Absorber

Bilstein SN2 Series shock absorbers feature a steel smooth body design utilizing the 46mm monotube technology (piston and piston band sold separately) designed for motorsports applications. These shock absorbers are available in non- single and double adjustable configurations in optimized lengths and can also be converted to a coilover design (kit sold separately). SN2 Series shock absorbers are ideal for racers whose sanctioning rules require steel body shock absorbers but allow for a user rebuildable design and aluminum end caps.

Plated steel body for durability and superior heat dissipation
46mm piston design for maximum damping control
Standard 1/2� graphite heims

ADDITIONAL INFORMATION

Bilstein 33-247823 SN2 Series - Suspension Shock Absorber

Adjustable Damping: Non-Adjustable
Body Design: Smooth Body Screw Top (Non-coilover)
Body Diameter (ID): 46mm
Body Material: Steel
Boot Included: No
California Proposition 65: WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov
Collapsed Length (IN): 11.00
Collapsed Length (MM): 279.4
Extended Length (IN): 15.82
Extended Length (MM): 401.9
Finish: Zinc Plated
Internal Design: Monotube
Lower Mount Type: 1/2in Heim
PartType: Shocks / Struts
Piston Type: Linear
Prop 65 (Y/N): Y
Segment: Motorsports
Series: SN2 Series
Spring Seat Included: No
Title: Bilstein Shock Absorbers
Upper Mount Type: 1/2in Heim
Valving Identifier: Linear Dry Kit (no valving)

FITMENT NOTES

No Applications
